Powerful performance in an elegant aluminum enclosure

The Piega Ace 50 Rx Wireless is an active 3-way floor-standing loudspeaker that, despite its slim form, delivers astonishingly full-bodied, deep, and controlled sound. Four 120mm woofers provide impressive bass pressure, while the MDS midrange driver and the precise AMT tweeter produce the typical, finely resolved Piega sound.

Integrated 200-watt amplifier for maximum headroom

With a total output of 200 watts, the loudspeaker effortlessly plays dynamically, richly detailed, and confidently – whether for music or film sound. Hi-res processing up to 24-bit / 192 kHz guarantees an absolutely clean, high-resolution playback.

Individually customizable sound

Three selectable sound filters allow the Ace 50 Rx to be optimally adapted to its placement in the room. Whether free-standing, near-wall or in acoustically challenging environments – the loudspeaker always remains balanced, clear, and controlled.

Combination with other devices in the Ace Wireless series (Tx/Rx & WiSA systems)

The Piega Ace Wireless series is designed to be flexibly combined and to work together wirelessly, stably, and in high resolution thanks to WiSA technology.
The following combinations are possible:

1. Ace Tx + Ace Rx (classic system)

Tx = Transmitting Unit

Rx = Receiving Unit

An Ace 30 Tx or Ace 50 Tx acts as the central transmitting station:
It receives music via WLAN/streaming/HDMI/optical/etc. and transmits the signal wirelessly to any Piega Ace Rx model.
The Ace 50 Rx Wireless can thus be used as a left, right, or center/rear loudspeaker.

2. Combination of multiple Rx loudspeakers

All Ace Rx models (Ace 30 Rx, Ace 50 Rx, Ace Center Rx) can:

• be networked directly with each other
• jointly receive the signal from a WiSA transmitter or an Ace Tx
• easily form a complete stereo or surround system



3. Use with WiSA-enabled televisions

The Ace 50 Rx can directly receive WiSA signals – entirely without an Ace Tx.
Compatible Smart TVs send multi-channel sound (up to 7.1) directly to the Piega loudspeakers.

Examples:

• LG OLED with WiSA Ready
• Samsung with WiSA Hub
• Xbox Series X/S + WiSA Hub



4. Use with external WiSA transmitters

If your TV or system does not have WiSA, an external transmitter can be used:

• WiSA SoundSend (on TV via HDMI eARC)
• Axiim Link
• Other certified WiSA hubs

The Ace 50 Rx Wireless is fully compatible and receives the signal loss-free.

5. Mixed systems Ace Tx + TV WiSA + additional Rx

The series allows for mixed installations:

• Two Ace 50 Rx as front
• An Ace 30 Tx for streaming playback
• Ace 30 Rx or Ace Center Rx for surround
• The system automatically sorts the channels (Left/Mono/Right).

Summary

The Ace 50 Rx Wireless is the most flexible receiver unit in the series and:

• works with Ace Tx loudspeakers
• receives wirelessly from WiSA TVs
• works with WiSA transmitters
• can be used in stereo, multiroom, or 7.1 home cinema systems

Specifications

• Principle: Active, 3-way
• Amplifier Power: 200 W total
• Frequency Response: 30 – 25,000 Hz
• Resolution: up to 24 Bit / 192 kHz
• Drivers:
  • 1 × Piega AMT tweeter
  • 1 × 120 mm MDS midrange driver
  • 4 × 120 mm MDS woofers
• Digital Inputs: 1 × Coaxial, 1 × Optical
• Analog Inputs: 1 × Cinch, 1 × Stereo-Balance In, 1 × Mono-In
• USB: 1 × USB-A (Service)
• Network: WLAN 2.4 / 5 GHz
• Dimensions: 14 × 16 × 104 cm
• Weight: 12 kg
• Colors: Black, Silver, White
• Series: Piega Ace Wireless

Special Features

• Active 3-way loudspeaker with integrated 200 W amplifier
• Four woofers for particularly powerful, clean bass
• AMT tweeter for detailed highs
• Room sound optimization via 3 sound filters
• WiSA-compatible – wireless reception up to 7.1 channels
• Premium aluminum casing
• Swiss development & manufacturing

Scope of Delivery

• Piega Ace 50 Rx Wireless
• Loudspeaker cover
• Power cable
• Documentation
