Powerful Sound with Broad Frequency Range

The speaker has a frequency response of 27 Hz to 40 kHz (+/-3 dB). This allows it to deliver deep bass as well as detailed highs.

Force-Balanced Array for Controlled Bass

The Force-Balanced Array uses four 6.5-inch woofers in a force-balanced configuration. The woofers work in such a way that cabinet vibrations are greatly reduced, and the bass is reproduced deeply, precisely, and evenly distributed.

Low Frequency with Bass Reflex Support / Distance to Wall

Two rear-firing 2.5-inch bass reflex ports support the low-frequency range. This gives the floor-standing speaker additional depth. It is important to place the speaker at a greater distance from the wall. We recommend a distance of 30 - 90 cm. The minimum distance is 15 cm.

Integrated, Diamond-Coated Tweeter for Clear Highs

Organic Cell Lattice Diffuser for Clean Dispersion

The FEA-optimized Organic Cell Lattice Diffuser sits in front of the tweeter. It protects the driver and supports controlled high-frequency dispersion.

Midrange Drivers for Voices and Instruments

Two 4.5-inch midrange drivers made of composite glass fiber material handle the important midrange. This is where many voices, guitars, pianos, and movie dialogues reside, which is why clean and stable reproduction is particularly important.

High-Quality Driver Construction

The midrange and woofers use baskets made of precision-cast aluminum alloy. This design ensures accurate component alignment and aids in heat dissipation during operation.

Time-Aligned Cabinet Geometry

The cabinet shape is designed to bring the acoustic centers of the drivers to as equal a distance as possible from the listening position. This allows high, mid, and bass frequencies to interact more coherently in time.

Acoustically Centered Architecture

Midrange and woofers are arranged rotationally symmetrically around the tweeter. This is intended to ensure that deep, mid, and high frequencies originate from a common acoustic reference point and form a cohesive sound image.

Low-Resonance Construction

The 25 mm thick driver baffle provides a stable base for the drivers. Additionally, the cabinet features an FEA-optimized 18 mm construction with bracing and sound insulation to reduce disturbing resonances.

Connection for Bi-Amping and Bi-Wiring

The gold-plated 5-way binding posts support bi-amping and bi-wiring. This means that the speaker offers two connection options: With bi-wiring, the high/mid-range and low-frequency range are connected from the same amplifier via separate speaker cables, while with bi-amping, separate amplifier channels or amplifiers are used for these ranges.

SVS Ultra Evolution Titan vs. Ultra Evolution Tower

The SVS Ultra Evolution Titan differs from the Ultra Evolution Tower primarily in its larger low-frequency foundation: While the Tower offers four 5.25-inch woofers and a frequency response of 30 Hz to 40 kHz, the Titan works with four 6.5-inch woofers and extends down to 27 Hz; this makes the Titan particularly suitable for larger rooms, higher sound levels, and noticeably more powerful bass reproduction, while the Tower remains the more compact floor-standing speaker variant in the series.

Specifications

General

• Manufacturer: SVS
• Product Name: SVS Ultra Evolution Titan
• Product Number: 102310
• Product Type: Floorstanding Loudspeaker
• Principle: 3-way Bass Reflex
• In-room Frequency Response: 27 Hz to 40 kHz (+/-3 dB)
• Cabinet Dimensions: 118.2 cm (H) x 24.9 cm (W) x 43.93 cm (D)
• Overall Dimensions incl. Grille, Feet and Binding Posts: 119.7 cm (H) x 30.0 cm (W) x 46.1 cm (D)
• Weight: 31.6 kg
• Warranty: 5 years

Acoustic and Electrical Data

• Nominal Impedance: 6 Ohm
• Efficiency / Sensitivity: 88 dB (2.83 V at 1 meter Full-Space, 300 Hz – 3 kHz)
• Recommended Amplifier Power: 20 – 300 Watts

Drivers

• Tweeter: 1" / 2.45 cm Diamond Coated Tweeter
• Tweeter Material: diamond-carbon-coated aluminum dome
• Tweeter Detail: FEA-optimized Organic Cell Lattice Diffuser
• Mid-range Driver: 2 x 4.5" / 11.43 cm made of composite glass fiber material
• Woofer: 4 x 6.5" / 16.51 cm in Force-Balanced-Array Principle
• Woofer: Long-throw driver with composite glass fiber cone
• Mid-range Driver Baskets: precision-cast aluminum alloy
• Woofer Baskets: precision-cast aluminum alloy
• Mid-range Driver Voice Coil Former: ventilated Kapton former
• Woofer Voice Coil Former: ventilated aluminum voice coil former

Crossover

• 3-way Crossover
• Components: high-quality capacitors, coils, resistors, and heavy-duty circuit board
• Crossover Frequency Tweeter to Mid-range Driver: 1.9 kHz
• Crossover Frequency Mid-range Driver to Woofer: 160 Hz

Enclosure and Construction

• Two 2.5" / 6.35 cm rear-firing bass reflex ports
• Acoustically transparent cover
• Cloth grille with magnetic retention system
• Screw-in elastomer absorber feet, horizontally adjustable
• Acoustically centered architecture
• Time-aligned cabinet geometry
• 25 mm thick driver baffle
• FEA-optimized 18 mm cabinet construction
• Bracing and sound insulation to reduce acoustic and structural resonances
• Beveled front baffle
• Flush-mounted drivers

Connections

• Gold-plated Bi-amping/Bi-wiring binding post terminal
• 5-way binding posts

Scope of Delivery

• SVS Ultra Evolution Titan
• Cover
• Equipment feet
• Spikes
• Mounting accessories
• Documents
