Description
POWERFUL CUSTOM INSTALLATION
Control up to four DALI PHANTOM loudspeakers
The DALI PHANTOM CI AMP-4750 DSP is a powerful custom installation amplifier
with advanced digital signal processing and loudspeaker presets that bring
the best out of any DALI PHANTOM installation setup. This rack-mountable
powerhouse is driven by 4 x 750 Watts of ultra-low distortion, Class-D amplification
and includes low-noise fan cooling, integrated protection circuitry, and a host
of connectivity options, including Wi-Fi, LAN, and GPIO. With any Wi-Fi-enabled
computer, tablet, or smartphone, the web-based PHANTOM AMP CONFIGURATOR also
offers intuitive configuration and control of up to four DALI PHANTOM loudspeakers
or eight subwoofers in any home cinema.
Key features at a
glance:
Tailored
sound
With a collection of speaker-specific presets,
the CI AMP-4750 DSP delivers the best possible sound.
Powerful Class-D amplification
4 x 750 Watts of Class-D amplification allows you to
drive amazing multi-speaker CI installations.
Full DSP
Powerful DSP tools ensure intuitive configuration and control
even of highly complex CI setups.
A wide range of applications
The CI AMP 4750-DSP perfectly suits high-performance home cinemas and multiroom installations.
Properties
Frequency Range [+/- 0.5
dB, 8 Ω load, 3 dB below rated power) [Hz]
12 - 20,000
Input Connectors
4 x Analog
unbalanced (RCA), 4 x Analog balanced (Euroblock connector), 1 x S/PDIF
(RCA)
Output Channels
4 x Lo-Z speaker (4 - 16 Ohm), 2 x Hi-Z speaker (70 V / 100 V), 1x
S/PDIF digital out (RCA)
Output Power [4 Ω]
4 x 750 W
(SE), 2 x 1,500 W (BTL)
Signal To
Noise Ratio (20 - 20 kHz, 8 Ω load) [dB]
106
(A-weighted)
Standby Consumption
[W]
0.5
THD+N (Typical)
[20 - 20k HZ, 8 Ω load, 3dB below rated power]
0.05 %
External Dimensions [HxWxD]
[mm/inch]
88 x 440 x 332 / 3.5 x 17.3 x 13.1
Weight [kg/lb]
7.22 /
15.91
Manufacturer information
Phantom CI AMP-4750 DSP
The DALI PHANTOM CI AMP-4750 DSP is a powerful Class D, rack-mountable, custom installation amplifier. With advanced integrated digital signal processing and loudspeaker presets, this 4x 750-watt powerhouse delivers the best in any DALI PHANTOM home cinema or multiroom installation. And with Wi-Fi/LAN connectivity and a web-based configurator, even complex setups are made easy.
