Digital Input

COAXIAL & OPTICAL
PCM 16-24Bit /44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz
DSD 2.8MHz (DoP)

HDMI ARC
PCM 16-24Bit /44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz

USB AUDIO
PCM 16-24Bit /44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz, 352.8kHz, 384kHz, 705.6kHz, 768kHz
DSD 2.8MHz, 5.6MHz, 11.2MHz (DoP)
DSD 2.8MHz, 5.6MHz, 11.2MHz, 22.4MHz (Native)

Aux In

SNR
100dB A-weighting

THD+N
< 0.004% @ 1k, <0.004% @ 20Hz-20kHz

FREQUENCY RESPONSE
20Hz-20kHz ±0.1 -3dB @ 40kHz

CROSSTALK
>-105dB

MAX INPUT LEVEL
2.1VRMS

Line Out

XLR
SNR：123dB A-weighting
THD+N：< 0.00018% @ 1k, < 0.00022% @ 20Hz-20kHz
Frequency Response：20Hz-20kHz ±0.1 -3dB @ 80kHz
Crosstalk：>-140dB
Output Level：4.5VRMS @ 0dB / 0~4.5VRMS Adjustable

RCA
SNR：120dB A-weighting
THD+N：< 0.00020% @ 1k, <0.00022% @ 20Hz-20kHz
Frequency Respons：20Hz-20kHz ±0.1 -3dB @ 80kHz
Crosstalk：> -120dB
Output Level：2.2VRMS @ 0dB / 0~2.2VRMS Adjustable

SUB
Cutoff Frequency：150Hz @ -3dB
Output Level：2.2VRMS @ 0dB / 0~2.2VRMS Adjustable

Headphone Output

4.4MM BALANCED
SNR：119dB A-weighting
THD+N：< 0.0004% @ 20Hz-20kHz 4VRMS
Frequency Response：20Hz-20kHz ±0.5 -3dB @ 22kHz
Output Impedance：< 2Ω
Output Power：1000mW @ 33Ω,  1000mW @ 300Ω,  500mW @ 600Ω, 1%THD
Gain：+12dB

6.35MM UNBALANCED
SNR：116dB A-weighting
THD+N：< 0.0004% @ 20Hz-20kHz 2VRMS
Frequency Response：20Hz-20kHz ±0.5 -3dB @2 2kHz
Output Impedance：< 1Ω
Output Power：1400mW @ 33Ω, 250mW @ 300Ω, 130mW @ 600Ω, 1%THD
Gain：+12dB

Network

LAN
10/100/1000 Mbps

WI-FI
2.4 GHz / 5 GHz

USB

2 x USB 3.0
The USB port provides a maximum power of 5V/1A.
The USB port works with devices which conform to the USB mass storage standard and supports FAT, FAT32, exFAT, and NTFS file formats, but is not guaranteed to be compatible with all storage devices.

Trigger

TRIGGER IN
DC 6-12V<10mA

TRIGGER OUT
DC 12V/50mA MAX

Storage Extension

M.2 2280 2260 2242 NVMe PCIe SSD slot
SSD supporting PCIe 3.0/4.0/5.0 standards，The maximum power specification provided by the expansion slot is DC 3.3V3A.

Power

AC INPUT
Wide voltage switching power supply
Power Voltage: AC 100V-240V 50/60Hz
Standby Power Consumption: < 5W
MAX Power Consumption: < 35W

DC INPUT
External power voltage: DC 12V ±10%
External power wattage: Larger than 36W
Power plug: Outer diameter 5.5mm; inner diameter 2.1mm (+ for inner, - for outer)

Weight & size

WEIGHT
2.89kg

DIMENSION
Width: 280 mm
Depth: 210 mm
Height: 82 mm

Accessories

Power cable 1x
IR Remote 1x
Printed material 1x
